The Hitachi ZW compact series wheel loaders redefine comfort and reliability for compact design loaders. The perfect tool in a variety of applications, the strong compact design allows for greater degrees of functionality and mobility.
- Overview
- Technical Info
- Download PDF
Hitachi ZW30-5B
- 18.2kw Engine Rated Power
- 0.4m3 Bucket Capacity
- 3205kg Operating Weight
- Engine
- Power train
- Axle and final drive
- Tires
- Brakes
- Steering system
- Hydraulic system
- Service refill capacities
Model : KUBOTA “D1703-M-DI-E4B” diesel engine
Type : 4-cycle, water-cooled, direct injection
No. of cylinders : 3
Bore and stroke : 87 mm x 102 mm
Piston displacement : 1.65 L
Batteries : 1 x DC 12V 64Ah 565CCA
Air cleaner : Dry type (Double element)
Transmission control : Hydrostatic transmission (HST) automatically controls power and 2-speed
Travel speed forward
1st : 7.0 km / h 7.0
2nd : 15.0 km / h
Travel speed reverse
1st : 7.0 km / h
2nd : 15.0 km / h
Drive system : Four – wheel drive system
Front & rear axle : Semi – floating type
Front : Fixed to the front frame
Rear : Trunnion support
Final drives : Heavy-duty, planetary, mounted inboard
standart : 12.5 / 70 – 16 6PR (L2)
Parking brake : Spring applied, hydraulically released wet disc
Service brake : Wet discs in reduction gear box
Type : Articulated frame steering
Steering angle : Each direction 41 total 82
Cylinders : Double-acting piston type
No. x Bore x Stroke : 1 x 55 x 228 mm
Steering mechanism : Full hydraulic power steering unit , pilot operation
Arm and bucket are controlled by mechanical single control lever
Relief pressure setting : 20.6 MPa
Hydraulic cycle times Arm raise : 5.0 s
Arm lower : 3.0 s
Bucket dump : 1.0 s
Filters : Full-flow 10 micron return filter
Fuel tank : 42 L
Engine coolant : 4.5 L
Engine oil : 5.6 L
Front axle differential & wheel hubs : 4.5 L
Rear axle differential & wheel hubs : 4.5 L
Hydraulic reservoir tank : 27 L
